Description
The GBAII+ is a Zorro RTG graphics card based on the Piccolo SD64 for the Amiga 2000, 3000 and 4000.
Features
RTG graphics card based on the Cirrus Logic GD5434:
- 64-bit blitter
- 110 or 135 MHz in 8-bit modes
- 85 MHz in 16-bit modes
- 45 MHz in 24-bit modes
- 2 MB on-board graphics RAM
- Picasso96-compatible driver
Screen Modes
Maximum refresh rate per colour depth:
| Resolution | 24-bit | 16-bit | 8-bit |
|---|---|---|---|
| 640×480 | 100 Hz | 200 Hz | 260 Hz |
| 800×600 | 65 Hz | 120 Hz | 120 Hz |
| 1024×768 | – | 75 Hz | 100 Hz |
| 1152×864 | – | 70 Hz | 85 Hz |
| 1280×720 (16:9 HD Ready) | – | 70 Hz | 85 Hz |
| 1280×1024 | – | – | 60 Hz |
| 1440×1080 | – | – | 55 Hz |
| 1560×1170 | – | – | 50 Hz |
This RTG graphics board can be combined with the OCS/ECS/AGA Flicker-Fixer/Scan-Doubler (see product images 5 and 6). The combination switches automatically between RTG and native Amiga screen modes.
Drivers
You can use the free Picasso96 version 2.0 driver from aminet.net, or buy the newer Picasso96 version 3.x drivers from Individual Computers.
Legal
This shop holds an official licence from Matthias Heinrichs for this product. Royalties are paid for every unit sold.
